Kioti CS2520H - $20,840 (Bakersfield)
1201 Union Avenue
QR Code Link to This Post
Engine Gross Power 24.5 hp (18.3 kW)
Rated Speed 3,200 rpm
No. of Cylinders 3
Fuel Type Diesel
Displacement 61.5 cu in. (1,007 cc)
Fuel Tank Capacity 6.7 gal. (25.5 L)
Transmission
Transmission Type Hydrostatic
Main Gear Hydrostatic
No. of Travel Speeds - Forward / Reverse Infinite, 2 Range
Min. Travel Speed of Forward w/ Ag @ Engine rated speed 0 mph (0 km/h)
Max. Travel Speed of Forward w/ Ag @ Engine rated speed 9.57 mph (15.4 km/h)
Power Take-Off
PTO Type Independent
PTO Power 18.5 hp (13.9 kW)
Rear PTO Speeds(1st) 540 rpm
Mid PTO Speeds 2,200 rpm
Brakes and Clutch
Brakes Wet Multi Disc
Dimensions w/ AG Tire
Length w/ 3-point hitch 99.3 in. (2,523 mm)
Width 45.9 in. (1,168 mm)
Height From Top of the Highest Point 88 in. (2,226 mm)
Wheelbase 55.1 in. (1,400 mm)
Ground Clearance 6.4 in. (162 mm)
Front Tread Ag Tires - Min 44.6 in. (1,133 mm)
Rear Tread Ag Tires - Min 46 in. (1,168 mm)
Turning Radius w/ Brake 8.2 ft. (2.54 m)
Hydraulics
Total Pump Flow 6.97 gpm (26.4 L/min)
3-Point Hitch
Standard Category Category 1
Maximum Lifting Capacity (24”aft. of hitch) 700 lbs. (318 kg)
Control Type Position
Weight
Weight w/ Ag Tires w/ ROPS 1,554 lbs. (705 kg)
Dealer:
San Joaquin Tractor
1201 Union Ave
Bakersfield, CA 93305
